| Productnaam: | Rookarme halogeenvrije XLPE geïsoleerde kabel | Sollicitatie: | Metrotunnels, stations en openbare gebouwen |
|---|---|---|---|
| Geleidermateriaal: | Klasse 2 gestrand gegloeid koper, IEC 60228 | Nominale spanning: | 0,6/1 kV (Um 1,2 kV) |
| Kern en dwarsdoorsnede: | 5 x 16 mm2 | Isolatiemateriaal: | XLPE, nominale dikte 0,7 mm |
| Schedemateriaal: | LSZH Thermoplastisch polyolefine, halogeenvrij | Rookdichtheid: | Lichtdoorlatendheid boven 60 procent volgens IEC 61034 |
| Emissie van zure gassen: | Minder dan 5 mg/g volgens IEC 60754-2 | Ontwerpstandaard: | IEC 60502-1, IEC 60332-1 |
| Markeren: | 5x16mm2 Copper XLPE Insulated Cable,Low Smoke XLPE Insulated Cable,Halogen Free XLPE Insulated Cable |
||
Product Overview Five core 16mm2 distribution cable for tunnels, stations, hospitals and other enclosed spaces where a fire must not turn the escape route into a smoke-filled shaft. The LSZH oversheath contains no halogen and no PVC, so combustion produces very little hydrogen chloride gas and light transmittance stays above the sixty percent threshold in the IEC 61034 test. Copper conductors keep the resistance low, while the XLPE insulation tolerates a 90 C conductor
