| Name: | XLPE Electrical Cable | Conductor: | Copper Conductor, Cl.2 as per IEC 60228 |
|---|---|---|---|
| Conductor Screen: | Semi-conductor | Insulation: | XLPE insulation (cross-linked polyethylene) rated at 90 OC |
| Insulation Screen: | Semi-conductor | Screen: | Copper tape |
| Sheath: | PVC or FR-PVC type ST2 to IEC 60502, black | Core: | Three Core |
| Corporation: | shenghua group | Brand: | Sh Cable |
| Markeren: | 33kV copper power cable,XLPE insulated 3-core cable,KEMA-certified power cable |
||
| Attribute | Value |
|---|---|
| Name | XLPE Electrical Cable |
| Conductor | Copper Conductor, Cl.2 as per IEC 60228 |
| Conductor Screen | Semi-conductor |
| Insulation | XLPE insulation (cross-linked polyethylene) rated at 90°C |
| Insulation Screen | Semi-conductor |
| Screen | Copper tape |
| Sheath | PVC or FR-PVC type ST2 to IEC 60502, black |
| Core | Three Core |
| Corporation | Shenghua Group |
| Brand | Sh Cable |
33kV Three Core Copper Conductor XLPE Insulated Medium Voltage Power Cable
Shenghua redefines resilience for medium-voltage (33kV) power networks with its triple-core copper-conductor XLPE cables, engineered to deliver uninterrupted energy for smart grids, industrial hubs, and disaster-prone regions. Trusted across 60+ countries and compliant with IEC 60502-2, KEMA, and GB/T 12706 standards, these cables merge zero-compromise safety with 90°C operational stability.
| Infrastructure | Shenghua Solution | Performance Proof |
|---|---|---|
| Offshore Wind Farms | Salt-spray-resistant XLPE + hermetic seals | 0.0991Ω/km (3×185mm²); 90°C continuous load in humid zones |
| Metro Tunnels | FR-PVC sheath + bend radius ≤15× OD | 91kV/5min dielectric test; 30-year design life |
| Smart Grids | EMI-shielded copper tape screen | Zero interference in Surabaya's IoT grid (2023-present) |
The medium voltage cable can be chosen for laying indoors and outdoors. Able to bear certain traction during installation, but not external mechanical forces. Laying single core cable in magnetic ducts is not allowed.
CE, RoHS, KEMA and more others at request
| Nom. Cross-section of conductor | Strands No./Dia. Of Conductor | Insulation Thickness | Sheath Thickness | Approx. O.D. | Approx. Weight | Max. D.C Resistance of Copper Conductor (20°C) | Testing Voltage A.C | Current Rating In air (A) | Current Rating In soil(A) |
|---|---|---|---|---|---|---|---|---|---|
| 3 × 50 | 10/2.52 | 10.5 | 3.5 | 78.6 | 5491 | 0.387 | 91 | 180 | 190 |
| 3 × 70 | 14/2.52 | 10.5 | 3.6 | 82.3 | 6649 | 0.268 | 91 | 220 | 230 |
| 3 × 95 | 19/2.52 | 10.5 | 3.7 | 85.9 | 7744 | 0.193 | 91 | 265 | 275 |
| 3 × 120 | 24/2.52 | 10.5 | 3.8 | 89.2 | 8833 | 0.153 | 91 | 305 | 315 |
| 3 × 150 | 30/2.52 | 10.5 | 3.9 | 92.8 | 10008 | 0.124 | 91 | 345 | 355 |
| 3 × 185 | 37/2.52 | 10.5 | 4.0 | 96.5 | 11381 | 0.0991 | 91 | 390 | 400 |
| 3 × 240 | 48/2.52 | 10.5 | 4.2 | 101.6 | 13408 | 0.0754 | 91 | 455 | 460 |
| 3 × 300 | 61/2.52 | 10.5 | 4.3 | 106.6 | 15520 | 0.0601 | 91 | 525 | 520 |
| 3 × 400 | 61/2.97 | 10.5 | 4.6 | 114.1 | 18942 | 0.047 | 91 | 600 | 590 |
We are factory in Hebei, China.
We usually quote within two hours after we received your inquiry. If you are urgent to get the unit price, please let me know. We can quote it ASAP.
When you confirm the quotation, we can offer you the sample for free. You just need to pay the freight.
It depends on your order quantity. If we have stock, 5 days is OK. If custom products, usually it's need 12 days.
Sure, we can make cables as you want. We can change the color and logo on cable as you want.
