Productdetails:
Betalen & Verzenden Algemene voorwaarden:
|
| Modelnaam: | PVC-geïsoleerde kabel 2 kern | Type geleider: | Aluminium |
|---|---|---|---|
| Grootte: | 1.5~800 m2 | Gratis monster: | Avalideerbaar |
| Isolatie kleur: | Elke kleur. | Garantie: | 1 jaar |
| bedrijf: | de groep shenghua | Merk: | Sh Kabel |
| Markeren: | 1kV Unarmoured Power Cable,Shenghua Power Cable Two Core,Sheathed Two Core Unarmoured Power Cable |
||
1kV Aluminum Conductor PVC Insulated & Sheathed Two Core Unarmoured Power Cable
Shanghai Shenghua Cable (Group) Co., Ltd.—ranked China’s #2 cable manufacturer and serving 30+ countries—delivers game-changing electrical solutions with its 1kV Two-Core Unarmoured Aluminum Conductor Cable. Engineered for cost-sensitive yet demanding environments, this cable merges lightweight design, fire safety, and global compliance to power modern buildings, factories, and renewable projects
| Conductor (mm²) | Max. Resistance (Ω/km) | Diameter (mm) | Test Voltage |
|---|---|---|---|
| 2×185 | 0.164 | 37.9 | 3.5kV/5min |
| 2×300 | 0.100 | 49.0 | 3.5kV/5min |
| 2×400 | 0.0778 | 56.0 | 3.5kV/5min |
| Full specs: 2×1.5mm² to 2×400mm² |
Applications
For laying indoors and outdoors. Able to bear certain traction during installation, but not external mechanical forces.
Application Standard: IEC/BS/UL/GB Standards
Construction
Conductor : Aluminum Conductor as per IEC 60228
≤6mm2 solid (class 1)
＞6mm2 stranded (class 2)
≥ 50mm2 Shaped (class 2)
Insulation : PVC(polyvinyl chloride) rated at 75℃
Sheath : PVC or FR-PVC type ST2 to IEC 60502, black or red or customization
Flame retardant: Avaliable as customization
Technical data
Rated voltage:1kV Low Voltage
Maximum Conductor Temperature: under normal (75℃), emergency (130℃) or short circuit no more than 5 s (160℃) conditions.
Technical parameter:
| Cross section of conductor | Thickness of insulation | Thickness of Sheath | Approx.cable diameter | Max.resistance of conductor at 20 ℃ | Test Voltage(AC) |
| mm2 | mm | mm | mm | ohm/km | KV/5min |
| 2x1.5 | 0.8 | 1.8 | 10.5 | - | 3.5 |
| 2x2.5 | 0.8 | 1.8 | 11.3 | 12.1 | 3.5 |
| 2x4 | 1.0 | 1.8 | 13.1 | 7.41 | 3.5 |
| 2x6 | 1.0 | 1.8 | 14.1 | 4.61 | 3.5 |
| 2x10 | 1.0 | 1.8 | 16.7 | 3.02 | 3.5 |
| 2x16 | 1.0 | 1.8 | 18.8 | 1.91 | 3.5 |
| 2x25 | 1.2 | 1.8 | 22.2 | 1.20 | 3.5 |
| 2x35 | 1.1 | 1.8 | 24.5 | 0.868 | 3.5 |
| 2x50 | 1.4 | 1.8 | 21.8 | 0.641 | 3.5 |
| 2x70 | 1.6 | 1.9 | 24.7 | 0.443 | 3.5 |
| 2x95 | 1.6 | 2.0 | 29.2 | 0.320 | 3.5 |
| 2x120 | 1.8 | 2.1 | 31.3 | 0.253 | 3.5 |
| 2x150 | 2.0 | 2.2 | 34.7 | 0.206 | 3.5 |
| 2x185 | 2.2 | 2.4 | 37.9 | 0.164 | 3.5 |
| 2x240 | 2.4 | 2.4 | 44.3 | 0.125 | 3.5 |
| 2x300 | 2.6 | 2.5 | 49.0 | 0.100 | 3.5 |
| 2x400 | 2.6 | 2.8 | 56.0 | 0.0778 | 3.5 |
